Quality Assurance System
- Quality Assurance System
Precision Inspection Methods & Full-Process Closed-Loop Quality Control
Zhuhai Jingmu has established a complete quality management system covering precision inspection equipment and standardized testing procedures. From design review, CNC machining, mold assembly, trial molding, sample inspection, to mass production, every stage is strictly controlled to ensure stable product quality and reduce production risks.
- All molds are custom-developed to order. Parameters shown across this site are reference values only — final specifications are confirmed after project evaluation.
DFM Analysis
Before mold development begins, our engineering team conducts professional DFM analysis based on 2D drawings, 3D models, and product requirements. We evaluate mold structure, manufacturability, material selection, and production feasibility to identify potential issues early and optimize the design.
Mold Precision Inspection and Process Control
Multi-stage inspections are conducted throughout the mold manufacturing process, with dimensional verification performed sequentially during CNC machining, EDM, polishing, and mold core assembly. Precision is strictly controlled regarding mold core cavities, inserts, sliders, the fit clearances of guide pillars and bushings, and the mating quality of parting surfaces. Geometric dimensioning and tolerancing (GD&T) as well as surface roughness are rigorously inspected in accordance with technical standards for the low- and medium-voltage electrical switchgear mold industry.
Product Trial & Inspection
After mold completion, we conduct trial molding and comprehensive sample inspection. Product dimensions, appearance, assembly performance, and functional requirements are carefully verified before final approval and delivery.
Finished Product Quality Control
Before shipment, every finished product undergoes strict quality inspection and traceability management. We check product appearance, dimensions, and performance to ensure compliance with customer requirements and provide reliable manufacturing solutions.
OEM — Mold Making From Your Drawings
ODM — New Product Joint Development
- Why Zhuhai Jingmold
Why Choose Zhuhai Jingmold
34 Years of Industry Experience, Serving Global Customers
With over 30 years of experience in the low-voltage electrical appliance industry, we have accumulated deep technical expertise and industry knowledge. We have long-term cooperation with more than 500 leading enterprises worldwide, providing professional mold design, process optimization, and technical support services. With a deep understanding of global customer requirements and strict quality standards, we offer reliable mold manufacturing and complete production solutions from product design to mass production.
Complete Professional Team Configuration
Zhuhai Jingmo has a complete professional team consisting of experienced engineers and technical specialists, including a 26-member engineering technology team, 10 mold structure design engineers, 6 project engineers, 2 injection molding engineers, and a 15-member quality control team. From early-stage DFM analysis, mold feasibility evaluation, and mold structure design to manufacturing, trial production, and project follow-up, the company provides complete internal coordination to ensure efficient communication and rapid resolution of technical challenges.
Complete Hardware and Quality Control System, Ensuring Quality and Delivery
The company is equipped with advanced mold manufacturing equipment, injection molding facilities, and professional testing instruments, establishing a complete production management and quality inspection system. Every stage, including machining, assembly, and trial production, undergoes strict inspection to ensure stable product quality and guarantee timely project delivery.
Customer-Oriented Service Philosophy
Zhuhai Jingmo focuses on customer project success by providing professional technical communication, transparent project management, and continuous after-sales technical support. By integrating domestic and international technical resources, including cooperation with European and German local service teams, the company provides timely communication, fast response, and proactive project management to help customers overcome various technical challenges.
Stable Material Supply and Traceability Management Capability
The company maintains long-term partnerships with reliable suppliers of raw materials, standard parts, steel, plastic materials, and BMC thermosetting materials. All materials can be traced and verified through a stable supply chain system, reducing project delays caused by material shortages and meeting global customer compliance and quality requirements.
Strong Project Risk Prevention and Management Capability
Zhuhai Jingmo conducts detailed DFM reviews, mold feasibility analysis, structural risk assessments, forming risk evaluations, and assembly risk analysis during the early stages of every project. By identifying potential problems before production begins, the company reduces mold modification costs, improves project efficiency, and helps customers save time and budget.
Mold Life Design for Large-Scale Production
For high-volume production of low-voltage electrical components, Zhuhai Jingmo provides durable mold design solutions with optimized structures, high-strength components, improved sliders, wear-resistant parts, and considerations for thermal expansion and BMC molding requirements. These solutions ensure long-term stable operation, reduce maintenance frequency, and meet customers’ large-scale production demands.
Complete Certification System Meeting International Requirements
Zhuhai Jingmo has established a complete certification and quality management system, including IATF16949, ISO9001, and ISO14001 certifications. The company follows standardized production processes with strict control over drawing management, manufacturing records, inspection reports, and traceability documentation, ensuring compliance with international customer auditing, inspection, and quality management requirements.
- START YOUR PROJECT
Have Drawings or a Sample? Get a Free DFM Evaluation
Upload your STEP / IGS / PDF drawing or sample photos and our engineering team will respond with a DFM assessment and project quote.
